cb-tec Stove VAIO IQ 33 XL
VAIO IQ - stove design & quality ‘Made in Germany’
The entire production, assembly and final inspection of the VAIO IQ stove series takes place exclusively in the two state-of-the-art CB production facilities in the Allgäu region. With over 50 years of experience in metal processing and one of the most modern natural stone production facilities in Europe, the VAIO IQ stands for the highest quality and long-lasting design.
Quality from a single source
From development and design to production and final inspection - everything is centralised in Germany. In this way, cb-tec guarantees precision, control and workmanship at the highest level.
Bicolour option for individuality
For even more visual variety, each natural stone top panel of the VAIO IQ can be finished in a different type of stone to the side panelling - a stylish design feature with character.
Natural Heat Storage
All VAIO IQ 33 XL models are equipped with a solid natural stone storage block. This ensures long-lasting and even heat distribution – even long after the fire has burned out.
VAIO IQ - When technology, design and craftsmanship merge into a masterpiece.
Performance data:
- NW output, kW: 6.3
- Efficiency, % : > 80.0
- Flue gas mass flow at NW, g/s: 4.7
- Flue gas temp. flue gas spigot, °C: 302
- Minimum conveying pressure at NW, Pa: 12
- Energy efficiency class: A+
- Combustion air requirement, m3/h: 12.85
- Max. Max. amount of wood kg/h: 1.95
- Flue pipe diameter ø in mm: 150
- Height in cm (rear outlet): 99.7
- Combustion air outlet (rear and bottom possible**) Diameter ø in mm: 100
Tests | Approvals
DIN EN 13240: yes
EN 16510-2-1: yes
1st BlmSchV. | 2nd BlmSchV.: yes | yes
Room air-independent: yes
Italy: no
Denmark: yes
Technical data Dimensions | Weight:
VAIO IQ 33 Steel XL height/width/depth in cm: 117.50*/54/48
VAIO IQ 33 Stone XL Top 1 height/width/depth in cm: 118.50/60/48
VAIO IQ 33 Stone XL Top 2 height/width/depth in cm: 125/60/48
VAIO IQ 33 Stone XL Top 3 height/width/depthin cm: 131.50/60/48
Weight in kg (approx.) Steel XL: 280* ,Stone 1: 420, Stone 2: 460, Stone 3: 500
Max. log length in cm 33 discs Log length in cm 33
Glass dimensions in cm (W x D x H) 36 x 6 x 46
Versions:
Steel
Steel with top slab natural stone
Stone with top slab 1
Stone with top slab 2
Stone with top slab 3
Natural stone types: Nero Marsala / Grigio Augusta / Beige Matera / Beige Vittoria
Scope of delivery: wood-burning stove, black steel railing handle, high-quality 3-piece fireplace set
Options: Oiled oak railing handle, polished stainless steel railing handle, additional stone top plate, black fireclay, combustion control, spark protection plate
This stove meets the current 2nd stage of the BImSchV and can of course be operated beyond 2024, with no time limit!
