Spartherm Stove SAPHIR RLA/RLU

Spartherm Stove SAPHIR RLA/RLU

Eye-catcher in a compact format
Perfect for small rooms: the innovative Lean Saphir fireplace system impresses with its clear, minimalist design and exceptionally shallow appliance depth. This means that no valuable space is wasted - every centimeter of the room can be used optimally!

Nice extra: The wide front panel of the small wood-burning stove offers an impressive view of the fire.
Another plus: Spartherm offers a wide range of colors to choose from for the cladding elements - so individual design wishes can be fulfilled.
And particularly practical: Like all fireplace systems from Spartherm, the Saphir is already pre-assembled. This makes it extra time-saving to install. This means less time and stress during installation!

The LIVING FIRE stoves* from Spartherm stand for modern flame play and exclusive elegance and bring a unique atmosphere into your home with their innovative technology and sophisticated design. Manufactured in Germany and equipped with high-quality materials, these wood-burning stoves offer a perfect combination of sustainability and individual style.

Highlights of the LIVING FIRE stoves:
- Customisable design: for a personalised experience, many models in the LIVING FIRE range can be adapted. Whether in the choice of materials, size or specific design details - each stove can be customised to fit harmoniously into a wide variety of room concepts.
- S-Thermatik NEO basic combustion control: This innovative control system ensures particularly efficient combustion by making optimum use of the fuel. The system reduces emissions and promotes even combustion - a sustainable option that helps to conserve resources and maximise heating output.
- Optional heat storage system: Heat storage elements are available on request for extended heat output. They retain the heat even after the fire has gone out, creating a long-lasting, cosy ambience in the room.
- The elegance of the round shape: Models such as the Ambiente impress with their round shape and clear lines. Their minimalist design blends stylishly into any interior design concept - from modern to classic. The Ambiente wood-burning stove has an elegant presence, but remains discreet and does not take away from the openness of the room.

A LIVING FIRE wood-burning stove from Spartherm transforms any room into a stylish, cosy retreat.

Technical Data

• Manufacturer: SPARTHERM
• Energy efficiency class : A+
• Nominal heat output (closed) kW: 7.5
• Heat output range kW: 5.3 - 9.8
• Efficiency % : >80
• Fuel: Logs
• Combustion system: Closed combustion, dependent or independant on room air
• Glass version: Standard glass, 1-piece
• Door design: Sliding door
• Flue pipe connection diameter mm: 150
• Flue pipe connection top/rear: yes/yes
• Supply air connection: yes 100 and 125 mm
• Dimensions W/H/D mm: 764/1600/442
• Weight kg: 330
• Material: Steel body
• Combustion chamber lining: Eboris ultra colour ivory (optional black)
• Operation possible with type A1 : yes
• Operation possible with type A : --
• Tests: BImSchV. 2nd stage, DIN EN 13240, Aachen/Munich/Regensburg regulation, Ecodesign 2022

Please select how the fireplace is to be installed; there are two model options: flush-mounted or freestanding.

Optional accessories:
Rear wall¹ for free-standing installation in cladding color / raw steel
Fireclay black (eboris 1300 ultra)
Storage set on top
Glass front panel (straight installation panel, combustible and non-combustible rear panel)
¹ Rear panels designed with a closable lead-through (dummy cover) for connecting the flue gas and combustion air duct.
Rear panels without blind cover (top/bottom connection) available as a special design. Please request these separately.

Smart fireplace assistance functions
S-Thermatic NEO
S-Thermatic NEO basic
S-USI II
S-ESAM 3.0


Important note: Before purchasing, please speak to your local district chimney sweep and obtain authorisation from them to operate the desired fireplace.
