Spartherm Stove ZIRKON 2L RLA/RLU

Spartherm Stove ZIRKON 2L

Zirkon 2L: Imposing, powerful and timelessly beautiful with view from 2 sides

The five fireplace systems Poseidon, Zirkon, Apollon, Ares and Artemis not only combine proven Spartherm premium quality with maximum ease of use, but also set completely new design accents with their successful symphony of imposing size and linear elegance.

A unique feature of these models is that they can be installed directly in front of the wall - without the wall clearance required by conventional stoves. This is made possible by innovative rear insulation, which ensures maximum space savings and stylish integration.

Other patented Spartherm innovations such as the all-round panel that automatically lowers when the glass is opened or the smooth-running slide-up technology are included in all models, as are smart fireplace assistance functions that can be operated via smartphone or tablet. So no matter which model you choose: You have arrived at the Olympus of wood-burning stoves!

The LIVING FIRE stoves* from Spartherm stand for modern flame play and exclusive elegance and bring a unique atmosphere into your home with their innovative technology and sophisticated design. Manufactured in Germany and equipped with high-quality materials, these wood-burning stoves offer a perfect combination of sustainability and individual style.

Highlights of the LIVING FIRE stoves:
- Customisable design: for a personalised experience, many models in the LIVING FIRE range can be adapted. Whether in the choice of materials, size or specific design details - each stove can be customised to fit harmoniously into a wide variety of room concepts.
- S-Thermatik NEO basic combustion control: This innovative control system ensures particularly efficient combustion by making optimum use of the fuel. The system reduces emissions and promotes even combustion - a sustainable option that helps to conserve resources and maximise heating output.
- Optional heat storage system: Heat storage elements are available on request for extended heat output. They retain the heat even after the fire has gone out, creating a long-lasting, cosy ambience in the room.
- The elegance of the round shape: Models such as the Ambiente impress with their round shape and clear lines. Their minimalist design blends stylishly into any interior design concept - from modern to classic. The Ambiente wood-burning stove has an elegant presence, but remains discreet and does not take away from the openness of the room.

A LIVING FIRE wood-burning stove from Spartherm transforms any room into a stylish, cosy retreat.

Technical Data

• Manufacturer: SPARTHERM
• Energy efficiency class : A+
• Nominal heat output (closed) kW: 7.9
• Heat output range kW: 5.5 - 10.3
• Efficiency % : 81
• Fuel: Logs
• Combustion system: Closed combustion, dependent or independant on room air
• Glass version: Standard glass, 2-pieces
• Door design: Sliding door
• Flue pipe connection diameter mm: 150
• Flue pipe connection top/rear: yes/yes
• Supply air connection: yes 100 mm
• Dimensions W/H/D mm: 824/1600/444
• Weight kg: 321
• Material: Steel body
• Combustion chamber lining: Eboris ultra colour ivory (optional black)
• Operation possible with type A1 : yes
• Operation possible with type A : --
• Tests: BImSchV. 2nd stage, DIN EN 13240, Aachen/Munich/Regensburg regulation, Ecodesign 2022

Please select how the fireplace is to be installed; there are three model options: flush-mounted against a wall, freestanding, or flush-mounted in a corner.

Optional accessories:
Rear wall¹ for free-standing installation in cladding color / raw steel
Fireclay black (eboris 1300 ultra)
Glass plate
Storage set on top (only available for free standing version!)
¹ Rear panels designed with a closable lead-through (dummy cover) for connecting the flue gas and combustion air duct.
Rear panels without blind cover (top/bottom connection) available as a special design. Please request these separately.
² If the panelling is installed flush with the wall on one side (on the side or rear wall), the beam protection set MUST also be ordered.

Smart fireplace assistance functions
S-Thermatic NEO
S-Thermatic NEO basic
S-USI II
S-ESAM 3.0


Important note: Before purchasing, please speak to your local district chimney sweep and obtain authorisation from them to operate the desired fireplace.
